GPUAMD Radeon™ RX 9060 XT Graphics Card
AMD RDNA™ 4 ArchitectureEngine ClockBoost Clock: Up to 3290 MHz
Game Clock: Up to 2700 MHzBoost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.Stream Processors2048Compute Units32 CUs (3rd Gen RT + 2nd Gen AI Accelerators)Infinity Cache32MbRay Accelerators32AI Accelerator64Memory Size / Bus16GB/128 bit GDDR6Memory Clock20 Gbps EffectiveDisplaysMaximum 3 DisplaysResolutionHDMI®: 7680×4320
DisplayPort™ 2.1a: 7680×4320InterfacePCI-Express 5.0 x16Output2x HDMI®
1x DisplayPort™ 2.1aBIOS SupportUEFIGame Index1440PSapphire FeaturesHoneywell PTM7950 Thermal Interface Material (TIM)
AeroCurve Fan Blade
Free Flow
FrameDefense
Integrated Cooling Module
Dual-X Cooling Technology
High TG Copper PCB
Optimized Composite Heatpipes
Metal Backplate
Sleeve Bearing Fans
9-Phase Digital Power Design
Fuse Protection
Intelligent Fan Control
Precision Fan Control
TriXX Supported
TriXX BoostAMD FeaturesAMD RDNA™ 4 Architecture
32 Compute Units (3rd Gen RT + 2nd Gen AI Accelerators)
AMD HYPR-RX with AFMF 2
AMD FidelityFX™ Super Resolution 4 with AI Upscaling
DisplayPort™ 2.1a
AMD Radiance Display™ Engine
AMD Fluid Motion Frames 2 technology
AMD Radeon™ Anti-Lag 2 technology
AV1 Encode/Decode
AMD FidelityFX™ technologies
Microsoft® DirectX® 12 Ultimate
AMD Noise Suppression
AMD Freesync™ technology
AMD Infinity Cache
16 GB of GDDR6 on 128-bit Memory Bus
AMD smart technologies
AMD Software: Adrenalin Edition™ applicationCooler TypeDual-X Cooling
AeroCurve Fan Blade
Free Flow
Integrated Cooling Module
High TG Copper PCB
Optimized Composite Heatpipes
Sleeve BearingForm Factor2.3 slot, ATX
Dimension: 240(L)X 124(W)X 46.1 (H)mmPower Consumption170W Typical Board PowerOSLinux®, Windows® 10, and Windows 11. 64-bit  operating system requiredSystem RequirementMinimum 450 Watt Power Supply
1 x 8-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB recommended.Warranty3 YearsNote****Prices, Specifications & Features are subject to change without notice
